AG-fit | AG-5 Gates

1280mmWysokość
1525mmHang height
550mm-6000mmGate length

Designed to be a quick and simple way to create customised penning arrangements
Padlockable spring bolts x2
Chain lashing capability on every gate slam stile end
Hinge pin is on a chain to prevent it getting lost

Find a stockist

Dodaj do listy życzeń

Ag-fit installation, operation & maintenance manual

AG-5 Gates
AG-5 Gates
AG-5 Gates
AG-5 Gates
AG-5 Gates
AG-5 Gates

Przegląd

The AG-fit 5 rail gates are high specification yard gates that are created using a Primary and a Gate Insert , which assemble telescopically to create the desired length. They are not designed to be variable length when in use.

Gates and panels can even be flipped or lifted for a 305mm rise to accommodate the build up of bedding. This can be done without moving brackets or the need for additional post hang positions.

About AG-fit:

The new AG-fit range from IAE is a modular off the shelf solution for all your cattle housing requirements. Primarily designed for loose housing, but also suitable for a wide variety of other applications. The easily assembled AG-fit range features an extensive collection of modular 5 rail two-part extendable gates and panels, waterers, posts and associated brackets to create a multitude of penning arrangements, all available your local IAE AG-fit stockist.

To watch our video about the AG-fit product range, click tutaj.

AG-5 Gates Recommended Combinations

Combined Gate Length (mm)	To Suit Nominal Opening** (mm)	Primary Product Code	Gate Insert Product Code
550 - 999	761 - 1210	1000112-01	F002 2004 01*
1000 - 1339	1211 - 1550	F002 2001 01	F002 2004 01
1340 - 1644	1551 - 1855	F002 2001 01	F002 2004 02
1645 - 1999	1856 - 2210	F002 2001 01	F002 2004 03
2000 - 2999	2211 - 3210	F002 2001 02	F002 2004 03
3000 - 3999	3211 - 4210	F002 2001 03	F002 2004 03
4000 - 4999	4211 - 5210	F002 2001 04	F002 2004 03
5000 - 6000	5211 - 6211	F002 2001 05	F002 2004 03
Insert may require cutting down to achieve length *Based on post and bracket hanging arrangement
